Electronic pressure measurement devices for Chemistry and Petrochemistry industry - Chemical & Pharmaceuticals
FromBD|SENSORS GmbH
Chemical processes make very high demands on electronic pressure measuring instruments and hydrostatic fill level probes in two respects: processes may be complex with high dynamic pressures and fast changing temperatures the media are diverse and may be chemically aggressive, explosive, toxic, abrasive and sometimes also dirty and viscous. Add to this top safety requirements, especially in explosion hazardous plant and equipment and the absolute demand for top operational reliability.
Most popular related searches
electronic pressure monitoring
pressure monitoring system
pressure monitoring
fill level monitoring
electronic monitoring system
electronic pressure monitoring system
level monitoring
distillation column
safety regulations
retention tank
- Pressure monitoring of tanks for gas and fluids
- Pressure measurement in distillation columns, supply systems and vessels (e.g. ammonia, solvents)
- Fill level measurements in storage tanks for fluids or sludge
- Fill level monitoring in distillation columns and retention tanks
- Fill level measurement for coolants, condensates and end products
- nominal pressures from 100 mbar to 1 000 bar
- fill heights from 1 m WG
- pressure connections and membranes made of materials suited for virtually all gases and fluids in the chemistry/petrochemistry sector, e.g. many stainless steels, Hastelloy, titanium, high-purity ceramics Al2O3 99,9% - polished etc.
- robust die cast aluminium or stainless steel field frames
- 4 - 20 mA / 2L design, display or HART communication optional
- accuracy classes from OEM via industrial and up to 0.1% standard accuracy class
- temperature ranges from -40 to +125°C; protection classes IP65 to IP69K
