8 products found

Products

  • Industry Products

  • Model 52.009.100 - Shut-Off Valve

    Model 52.009.100 - Shut-Off Valve

    The manual shut-off valve allows a complete shut-off of water paths for service e.g. pipe parts or other distribution circuits. The functionality according to DIN EN 13828 is confirmed by an accredited laboratory. The shut-off valve ensures a tight seal so that no pressure loss in the system occurs while still in operation. Thus the main applications are where the fluid path is to be shut off for service purposes (replacement of components) or for...

  • Model 52.009.200 - Manual Shut-Off Valve

    Model 52.009.200 - Manual Shut-Off Valve

    The manual shut-off valve allows a complete shut-off of water paths for service e.g. pipe parts or other distribution circuits. The functionality according to DIN EN 13828 is confirmed by an accredited laboratory. The shut-off valve ensures a tight seal so that no pressure loss in the system occurs while still in operation. Thus the main applications are where the fluid path is to be shut off for service purposes (replacement of components) or for...

  • Model 42.008.126 - Pressure Reducer

    Model 42.008.126 - Pressure Reducer

    The pressure regulator converts variable inlet pressures into a lower, constant outlet pressure. It can be used to protect equipment from high or inconsistent incoming medium pressure. This reduced and constant outlet pressure also enables a constant flow rate to be achieved independently of the incoming pressure. The orifice used to maintain this constant flow rate should be placed immediately after the pressure reducer. The pressure can easily be...

  • Model 24.006.125 Series - Direct Acting Solenoid Valve

    Model 24.006.125 Series - Direct Acting Solenoid Valve

    Series 24.006.125 valves are direct acting 2/2 way solenoid valves with an orifice size of 3 mm. They are used for control of hot and cold drinking water and other similar media particularly when a rapid opening and closing of the valve is required for accurate dosing. The valve is normally closed (NC). Valves of this design are single chamber straight through valves. Coil systems for common voltage and frequency ranges are available. Electrical...

  • Agriculture and Food Products

  • Model DN 10 - 2/2- Way Servo-Direct Stepper Motor Controlled Valve

    Model DN 10 - 2/2- Way Servo-Direct Stepper Motor Controlled Valve

    The 2/2 way servo-direct motorized valve has a 10mm orifice, but a continuously variable stroke to accurately control the flow through the valve. It can function with low inlet pressures and flow rates, similar in nature to a direct acting valve without a complete shut of function. The stepper motor drive part of the valve is completely separated from the medium by means of special PTFE bellows. This valve has been specifically developed for...

  • Model DN 10 - 2/2-Way Servo Controlled Solenoid Valve

    Model DN 10 - 2/2-Way Servo Controlled Solenoid Valve

    2/2-way solenoid valve of nominal diameter DN 10 for use with cold and heated potable water and physically and chemically similar media. The valve is servo-controlled and normally closed (NC). Valves of this design are double chamber valves with the inlet ninety degrees to the outlet and can be manufactured with various connections. Coil systems for common voltage and frequency ranges are available. Electrical operating safety is achieved by...

  • Model DN 40 - 2/2-Way Vacuum Controlled Direct Acting Drain Valve

    Model DN 40 - 2/2-Way Vacuum Controlled Direct Acting Drain Valve

    2/2-way direct acting drain valve of nominal diameter DN 40 for controlling low aggressive liquid media, such as cleaning or disinfection agents. Valves of this type are medium separated having a single chamber valve body with the inlet at ninety degrees to the outlet. They can be manufactured in various...

  • Model DN 40 - 3/2-Way Vacuum Controlled Direct Acting Dump Valve

    Model DN 40 - 3/2-Way Vacuum Controlled Direct Acting Dump Valve

    3/2-way direct acting dump valve of nominal diameter DN 40 for controlling low aggressive media, such as cleaning or disinfection agents. Valves of this type have a medium separated controll pressure chamber and can be manufactured in various materials equipped with threaded or hose connections. The Valve...
