BinMaster Sensors and Technologies LLC products

Continuous Level - 3D Level Scanner - MVL System

BinMaster - Model IECEx/ATEX - MVL- 730-0626-EX - 3D Level Scanner for Multiple Scanner Systems

IECEx/ATEX 3D Level Scanner - MVL is for use in multiple scanner systems that include the 3D visualization feature. It features a 7.67” diameter horn, 20-36 VDC, 4-20 mA output, Modbus, and RS-485 communications.When used in a multi-scanner system, it provides accurate readings of level and volume for stored materials based on two or more synchronized MVL units.

BinMaster - Model MVL -730-0626 - 3D Level Scanner for Multiple Scanner Systems

3D Level Scanner - MVL is for use in multiple scanner systems that include the 3D visualization feature. It features a 7.67" diameter horn, 20-36 VDC, 4-20 mA output, Modbus, and RS-485 communications.When used in a multi-scanner system, it provides accurate readings of level and volume for stored materials based on two or more synchronized MVL units.

BinMaster - Model MVL- 730-0644 - 3D Level Scanner for Multiple Scanner Systems

3D Level Scanner-MVL with extended temperature up to 365°F is for use in multiple scanner systems that include the 3D visualization feature. It features a 7.67” diameter horn, 20-36 VDC, 4-20 mA output / Hart protocol, and RS-485 communications. When used in a multi-scanner system, it provides accurate readings of level and volume for stored materials based on two or more synchronized MVL units.

BinMaster - Model 730-0648 - Multi-Scanner System Controller for 3DLevelScanner

3DLevelScanner multi-scanner system controller with 3DVision software. The software processes the measurement data recorded by each of the scanners in the multi-scanner system in the silo, open bin, or warehouse. A special algorithm combines the data from the scanners in the system and provides general vessel information as well as volume, minimum and maximum level, distance and mass. When used with 3DLS-MVL/HT/TC models, the software also provides a 3D visualization.
