Calgon Carbon Corporation products

Designed to treat flows up to 4.8 million gallons per day (15 MLD), the Sentinel 12 can effectively disinfect drinking water in small- to medium-sized treatment plants. The Sentinel 12 uses medium-pressure lamp technology to achieve greater than 4 log inactivation of Cryptosporidium and similar pathogens in drinking water. Medium-pressure lamp technology allows the Sentinel 12 to be compact with a small footprint. This can provide a significant advantage to water treatment plants looking for a system that can be easily retrofitted into existing treatment systems. The Sentinel 12 outperforms other advanced treatment technologies such as membranes and ozone at a fraction of the cost. The Sentinel 12 system features include independent, third-party-certified UV intensity sensors to assure accurate delivery of UV dose, an automatic quartz sleeve cleaning system, and a fully automated control system.

The C3500 open channel series is an advanced, cost effective solution for the ultraviolet disinfection of wastewater using high powered (500W), low-pressure lamps. Calgon Carbon designed the C3500 open channel, parallel flow ultraviolet disinfection series to meet the demands of treatment plant operators with simple operation and maintenance. The C3500 allows plant operators to eliminate chlorine usage, which eliminates the risks associated with chemical handling, while improving effluent quality.

Designed to treat flows up to 20 milfion gallons per day (75 MLD), the Sentinel 24 can effectively disinfect drinking water in medium-sized treatment plants. The Sentinel 24 uses medium-pressure lamp technology to achieve greater than 4 log inactivation of Cryptosporidium and similar pathogens in drinking water. Medium-pressure lamp technology allows the Sentinel 24 to be compact with a small footprint. This can provide a significant advantage to water treatment plants looking for a system that can be easily retrofitted into existing treatment systems. The Sentinel 24 outperforms other advanced treatment technologies such as membranes and ozone at a fraction of the cost. The Sentinel` 24 system features include independent, third-party-certified UV intensity sensors to assure accurate delivery of UV dose, an automatic quartz sleeve cleaning system, and a fully automated control system.

Designed to treat flows up to 27 million gallons per day (100 MLD), the Sentinel` 36 can effectively disinfect drinking water in medium- to large-sized treatment plants. The Sentinel 36 uses medium-pressure lamp technology to achieve greater than 4 log inactivation of Cryptosporidium and similar pathogens in drinking water. Medium-pressure lamp technology allows the Sentinel 36 to be compact with a small footprint. This can provide a significant advantage to water treatment plants looking for a system that can be easily retrofitted into existing treatment systems. The Sentinel 36 outperforms other advanced treatment technologies such as membranes and ozone at a fraction of the cost. The Sentinel 36 system features include independent, third-party-certified UV intensity sensors to assure accurate delivery of UV dose, an automatic quartz sleeve cleaning system, and a fully automated control system.

Designed to treat flows up to 40 million gallons per day (150 MLD), the Sentinel 48 can effectively disinfect drinking water in large-sized treatment plants. The Sentinel 48 uses medium-pressure lamp technology to achieve greater than 4 log inactivation of Cryptosporidium and similar pathogens in drinking water. Medium-pressure lamp technology allows the Sentinel 48 to be compact with a small footprint. This can provide a significant advantage to large water treatment plants looking for a system that can be easily retrofitted into existing treatment systems. The Sentinel 48 outperforms other advanced treatment technologies such as membranes and ozone at a fraction of the cost. The Sentinel 48 system features include independent, third-party-certified UV intensity sensors to assure accurate delivery of UV dose, an automatic quartz sleeve cleaning system, and a fully automated control system.
