Chemyx Inc products

The Fusion 100X syringe pump is a programmable modular dual-channel precision infusion syringe pump. This multiple syringe pump has the following features: two syringes to infuse simultaneously, a full-glass chemical resistant touch screen, a programmable multi-step mode, computer control with Lab view and other programs, an add-on 11-Syringe push rack to increase the syringes used to eleven. Fusion 100X can be used for dispensing/dilution, organ/tissue perfusion, and fluid circulation in chemical, pharmaceutical, and biotech R&D.

The Fusion 200X is a programmable, dual-channel infusion and withdrawal modular syringe pump. This advanced precision syringe pump features two syringes to infuse/withdraw simultaneously at pulseless, reproducible rates; a programmable multi-step mode that allows users to program complex multi-step flow rates; computer control with Lab view and other programs; an add-on 4-syringe push and pull rack for four large syringes; an add-on 11-syringe push and pull rack to increase the syringe number up to eleven. The Fusion 200X double syringe pump has a full-glass touch screen that is chemical resistant and easy to clean for lab environments of all types. This automated syringe pump is designed for precision dispensing/dilution, organ/tissue perfusion, and microfluidics, electrospinning, aerosols, pharmaceuticals, and bioscience research.

The Fusion 6000X high-pressure syringe pump is designed for dosing viscous solutions and semi-solid material against pressure with microfluidic pump precision. The Fusion 6000X temperature control syringe pump has the following unique features: 700 lb. linear pushing force, add-on syringe heater, add-on pressure sensor, modular 4 syringe expansion rack, and priming bottoms. These features allow the Fusion 6000X high-pressure syringe pump to increase syringe capacity to four, warming the syringe contents, and with pressure monitoring and control. Priming buttons allow adjusting the plunger’s position easily. The all-glass touch screen and heavy-duty mechanical structure, allow the Fusion 6000-X constant pressure syringe pump to be easy to clean and has high durability for industrial lab environments.

The Fusion 4000X is a motorized, multi-channel syringe infusion pump. It features a dual-independent channel infuse and withdraw syringe pump. It is built with 2 separate pump drives capable of independent pulseless, reproducible rates, and movement. Programmable multi-step and cycle mode that allows users to input complex flow profiles or perform flow cycling from a computer Labview or the pump itself. This motorized multi-channel syringe infusion pump system also can be expanded with a 2-syringe push and pull rack attachment to increase the total syringe capacity to four. Designed for a wide range of biopharmaceutical research like lipid nanoparticles, microfluidic mixing, and lab-on-chip flow control in drug formulation applications; with an all-glass touch screen and precision machined metal design, the Fusion 4000-X dual-channel syringe pump is easy to clean, for lab and GMP environments.

Fusion HP high-pressure syringe is a heavy-duty high-pressure syringe pump designed for elevated pressures in research, industrial, and manufacturing applications. This system delivers 1 Ton (2200 lbs) of pushing force and is the most powerful benchtop linear pump system on the market. This specialized high-pressure syringe pump is designed for demanding conditions associated with supercritical fluids, hydraulic fracturing, and nano-encapsulation which exist at temperatures and pressures beyond their critical points.

Fusion 4000X OEM is a bolt-on microfluidic syringe pump module designed for integration into customer-made analytical instruments requiring precision flow functionality with removable syringes. With the same specifications of Fusion 4000X syringe pump, the Fusion 4000X OEM module is configured with dual motors and two independently controlled precision syringe pump channels that allow independent dual-rate, push-pull, pulseless, reproducible flow rates, and oscillatory flow requirements for difficult research applications such as lipid nanoparticles, microfluidic mixing, and microfluidic flow control in drug formulation applications. The capability of adding two dual-syringe racks allows the Fusion 4000X OEM to hold four syringes. Like other OEM systems, the Fusion 4000X OEM micro syringe pumps can be controlled by a computer via Teraterm or a customer-created computer program.

The Chemyx OEM microsyringe pump module is a bolt-on microfluidic syringe pump designed for integration into analytical instruments requiring precision flow functionality with a removable syringe. OEM series microsyringe pumps are capable of delivering microliter accurate flows from a wide range of syringe sizes. This OEM syringe pump module system is ideal for a multitude of applications like an injection into a mass spectrometer, microfluidics, and diagnostic instrument integration.th and sized according to our Chemyx Stainless-Steel Syringes.

The Chemyx OEM syringe pump is a bolt-on infuse-only microfluidic pump designed for integration into analytical instruments requiring precision flow functionality with a removable syringe. OEM series pumps are capable of delivering microliter accurate flows from a wide range of syringe sizes. This OEM module system is ideal for a multitude of applications like injection into a mass spectrometer, and microfluidics, and diagnostic instrument integration. Learn more about this OEM bolt-on microfluidic pump system.

The Fusion 200 is a modular two-channel infusion and withdrawal syringe pump. This popular two-channel syringe pump model has the following features: two syringes to infuse and withdraw simultaneously at pulseless, reproducible rates; a programmable multi-step mode that allows users to program complex multi-step flow rates; computer control with Lab view and other programs; an add-on 10-syringe push and pull rack to increase the syringe number to ten. Fusion 200 dual syringe infusion and withdrawal pump have been proved to provide pulseless, reproducible flow rates for a wide range of analytical techniques and applications in chemical, pharma, and biotech R&D.

Chemyx Fusion 101A is a programmable infusion-only syringe pump that performs the most basic precision dispensing activities. This syringe pump comes with standard infuse mode and multi-step programmable mode. It also has an RS232 and USB port that allows the pump to be controlled by a computer. The programmable infusion pump can be used for mass spectrometry calibration, synthetic chemistry, electro-spinning, drug infusion, and ESI microliter injections. The upgrade of this model is Fusion100-X.
