93 products found

DILO Armaturen und Anlagen GmbH Products

  • SF6 Gas - SF6 Gas Refilling and Evacuating Devices

  • DILO - Model 3-393-R001/3-393-R002/3-393-R115 - SF6 Gas Refilling Device

    DILO - Model 3-393-R001/3-393-R002/3-393-R115 - SF6 Gas Refilling Device

    3-393-R001 - SF6 gas refi lling device for high voltage: Portable with rubber hose and couplings DN8 and DN20, Pressure range 0 up to 10 bar. 3-393-R002 - SF6 gas refi lling device for high voltage: Portable in a case with rubber hose and couplings DN8 and DN20, Pressure range 0 up to 10 bar. 3-393-R115 - SF6 gas refilling device for medium voltage: Portable in a case with rubber hose and couplings DN8 und DN6, Pressure range 0 up to 2,5 bar.

  • DILO - Model 3-001-R001 and 3-001-R002 - SF6 Gas Refilling Device

    DILO - Model 3-001-R001 and 3-001-R002 - SF6 Gas Refilling Device

    Refilling device as cylinder cart for comfortable on board carrying of a gas bottle. The primary gauge of the pressure reducer displays the bottle pressure in bar, psi and kPa, the secondary gauge indicates the desired filling pressure to be set easily by means of the handle. The bottle pressure can be reduced to the desired filling pressure by the integrated pressure reducer. During the refilling process emissions are avoided by self-closing...

  • DILO - Model 3-001-R021 - SF6 gas Refilling Device With Electronic Weighing Scales 0 - 120 kg

    DILO - Model 3-001-R021 - SF6 gas Refilling Device With Electronic Weighing Scales 0 - 120 kg

    Refilling device as cylinder cart for comfortable on board carrying of a gas bottle. The primary gauge of the pressure reducer displays the bottle pressure in bar, psi and kPa. The secondary gauge indicates the desired filling pressure to be set easily by means of the handle. The bottle pressure can be reduced to the desired filling pressure by the integrated pressure reducer. The weight of the gas to be refilled can be registered easily by means of...

  • DILO - Model 3-001-4-R002/3-001-4-R022/3-001-4-R122 - Evacuating and Refilling Device

    DILO - Model 3-001-4-R002/3-001-4-R022/3-001-4-R122 - Evacuating and Refilling Device

    In practice, the device covers two important functions. The integrated vacuum pump is the core component of the device. This vacuum pump evacuates the air down to < 1 mbar so that no air/gas mixture is produced during the subsequent filling process. The well proven DILO coupling principle ensures safe handling without emission. Using the 3-001-4-R022 version the filling weight can be registered comfortably by means of a weighing scale. The weight...

  • DILO CommGuard Web - Model B190R11 - Remote Commissioning Unit

    DILO CommGuard Web - Model B190R11 - Remote Commissioning Unit

    Finest hairline cracks may occur on porcelain insulators for circuit breakers or other SF6 insulated electrical equipment such as measuring or current transformers during transportation or as a result of material stress. Filling the gas compartment with SF6 may lead to dangerous bursting of the insulator. Thanks to the 'CommGuard Web' filling unit it is now possible, for the very first time, to fill porcelain insulators in a controlled and safe way...

  • SF6 Gas - Mobile Vacuum Pump Units

  • DILO - Model B046R03 and B046R13 - Mobile Vacuum Pump Unit

    DILO - Model B046R03 and B046R13 - Mobile Vacuum Pump Unit

    The mobile vacuum pump unit is convincing by its easy handling. The unit serves for evacuation of air or nitrogen from switchgear. The 40 m³/h vacuum pump (standard version) enables a fi nal vacuum of < 1 mbar. Thus it is guaranteed that no air/gas mixture can be generated and the excellent insulation properties of SF6 are maintained. The 2-stage vacuum pump (available as option) even reaches a fi nal vacuum of...

  • DILO - Model B046R20 - Mobile Vacuum Pump Unit

    DILO - Model B046R20 - Mobile Vacuum Pump Unit

    This vacuum pump unit is 'powerful' - its nominal suction capacity is 200 m³/h at 50 Hz for quick and reliable evacuation of air to a final vacuum of 1 mbar. This unit is particularly suitable for the evacuation of large gas compartments. Two coupling connections (DN20 and DN40) allow the evacuation of two gas compartments at the same time without any manifold that means more efficiency and higher productivity during operation.

  • DILO - Model Z300R11 and Z300R12 - Mobile Vacuum Pump Unit

    DILO - Model Z300R11 and Z300R12 - Mobile Vacuum Pump Unit

    This series is very powerful and allows quick evacuation of large gas compartments. A vacuum pump combined with a Roots pump enables to obtain a final vacuum of 2x 10-2 mbar. Thus not only air but also moisture is removed from the circuit breakers. Therefore the subsequent filling process is prepared perfectly. Three coupling connections (DN20 and 2x DN40) allow the evacuation of two gas compartments at the same time without any manifold that means...

  • SF6 Gas - SF6 Service Carts - Micro Series

  • DILO - Model B160R92S16 and B160R92S15 - Micro Series - Portable Service Unit for the Handling of Small SF6 Gas Quantities

    DILO - Model B160R92S16 and B160R92S15 - Micro Series - Portable Service Unit for the Handling of Small SF6 Gas Quantities

    This compact service unit has been specially designed for very small gas quantities and is perfectly suited for applications such as SF6 gas handling on medical devices, electron microscopes or medium voltage components. The device includes all functions required for professional and emission-free SF6 gas handling such as: gas recovery down to < 10 mbar, purification during the recovery and filling process, gaseous storage in an internal vessel or...

  • DILO - Model B160R11 & B160R11S15 - Mobile Service Unit for the Handling of Small Sf6 Gas Quantities

    DILO - Model B160R11 & B160R11S15 - Mobile Service Unit for the Handling of Small Sf6 Gas Quantities

    The compact service unit has been specially designed for very small SF6 gas quantities and is perfectly suited for applications such as SF6 gas handling on medical devices, electron microscopes or in research centres. The small and compact device includes all functions required for professional and emission-free SF6 gas handling: recovery down to 2 mbar, liquid storage in an external pressure vessel, evacuation of air down to 2 mbar as well as fi...

  • SF6 Gas - SF6 Service Carts - Mini Series

  • DILO - Model B143R11 - Compact and Mobile SF6 Gas Reclaimer

    DILO - Model B143R11 - Compact and Mobile SF6 Gas Reclaimer

    For efficient SF6 gas handling on small gas compartments. The compact and mobile SF6 gas reclaimer meets all requirements for efficient gas handling in the medium voltage range. Compact design and ergonomic aspects have been the main focus for its construction. The maintenance unit allows gas recovery down to a final vacuum of < 5 mbar and keeps pace with large devices. All necessary functions are integrated including gas purification via dry...

  • DILO - SF6 Service Carts

  • DILO - Model L030R02 - Piccolo Series - SF6 Gas Handling Device

    DILO - Model L030R02 - Piccolo Series - SF6 Gas Handling Device

    The L030R02 model of the Piccolo series has been specially designed for modern switchgear with small gas compartments. Due to its compact construction this device fits conveniently onto a euro pallet for transport and is easily manoeuvrable even in the very narrow passage ways of gas insulated switchgear. The device is operated via a 3.5” colour touch panel where icons are clearly displayed and allow a quick overview of the entire process. The...

  • DILO - Model B057R.. - Compact Series - SF6 Gas Recovery Unit

    DILO - Model B057R.. - Compact Series - SF6 Gas Recovery Unit

    This robust series comprises several versions allowing gaseous and liquid SF6 storage. SF6 gas can be recovered to a final vacuum of < 5 mbar or 1 mbar and exceeds IEC 62271-4 regulations by far. All devices of this type series are equipped with a semi-automatic control and are easy to operate: The functions are selected by means of a 3-way ball valve and a selector switch. The pressure units (bar/mbar, kPa or psi/torr) can be chosen on the...

  • DILO - Model L057R01 - Economy Series - SF6 Maintenance Unit

    DILO - Model L057R01 - Economy Series - SF6 Maintenance Unit

    This series not only captivates with its compact construction and modern design, but also combines state-of-the-art technology and ergonomics. It is a real all-rounder and covers all practical requirements on a user-friendly device. Everything is available: The integrated drawer for adapters and hoses as well as the digital weighing scales. Modern control technology in conjunction with a user-friendly interface in several languages make device...

  • DILO - Model L170R01 - Mega Series - Maintenance Device for Large and Extra Large Gas Compartments

    DILO - Model L170R01 - Mega Series - Maintenance Device for Large and Extra Large Gas Compartments

    Maintenance device for large and extra large gas compartments. The L170 service cart has been developed as entry-level model of the Mega Series for the gas handling on large gas compartments. Thanks to the state-of-the art control all functions run automatically and are displayed on a 10“ multi-touch screen. A new software with intuitive user navigation makes operation very easy and comfortable. This service cart can optionally be operated via...

  • DILO - Model L400R01; L600R.. - Mega Series - Maintenance Devices for Large and Extra Large Gas Compartments - SF6 Reclaimer

    DILO - Model L400R01; L600R.. - Mega Series - Maintenance Devices for Large and Extra Large Gas Compartments - SF6 Reclaimer

    Devices in this class are real 'power packs'. Their performance ensures that gas rooms are serviced quickly and that electricity can flow again quickly. Thanks to modern control, all functions run automatically and are displayed on a 10 'multi-touch panel. The operating software with intuitive user guidance makes operation simple and convenient. Optionally, the device can also be operated via mobile devices such as smartphones, tablets or laptops.

  • DILO - DILO - SF6 Storage Tanks

  • DILO - Pre-Filter and Separating Units

    DILO - Pre-Filter and Separating Units

    Adsorption of humidity and decomposition products. On the assumption that contaminated or humid gas is in the circuit breaker we recommend the use of pre-filters between switchgear and service cart. Moisture, gaseous and dusty decomposition products as well as oil aerosols are adsorbed by special dry and particle filters during the recovery operation. Thus, service carts are protected effectively against contamination as most of the moisture and...

  • DILO - Model B176R.. - SF6 Gas Storage Tanks

    DILO - Model B176R.. - SF6 Gas Storage Tanks

    These tanks offer sufficient volume to store or withdraw even large gas quantities in gaseous or liquid form – special feature of this type series: for withdrawal of liquid gas, the entire gas content can be withdrawn all at once without having to heat the tank. The tanks are equipped with digital weighing scales. These weighing scales enable to determine the filling weight with an accuracy of ± 500 g, thus facilitating considerably the...

  • DILO - Model 3-718-R006 / 3-718-R036 / 3-718-R002 - Manifolds for Gas Handling

    DILO - Model 3-718-R006 / 3-718-R036 / 3-718-R002 - Manifolds for Gas Handling

    The DILO manifolds help to significantly increase the efficiency of gas handling with service carts in the GIS unit production or at utility companies. The standard DILO manifolds are equipped with three DN20 connections as well as a DN20 or DN40 connection ton to the service cart. Thus, it is possible to recover, to evacuate or to fill three gas compartments at the same time.

  • DILO - Model K176R21 / R31 / R32 - Remote Control Router in Transport Case

    DILO - Model K176R21 / R31 / R32 - Remote Control Router in Transport Case

    The flexible K176R21 / R31 / R32 routers allow remote access to the connected DILO device via the Internet. The router is protected in the transport case and can be magnetically attached to a wide variety of devices with just a few simple steps. The Internet connection is possible via LAN or mobile network. Error analysis, operation or software adaptation of the connected devices can thus be carried out quickly and easily by our specialists from the...

  • SF6 Gas Cylinders

  • DILO - Gas Cylinder for New Gas (Without Filling)

    DILO - Gas Cylinder for New Gas (Without Filling)

    New SF6 as well as used SF6 with a SO2 content of < 250 ppmv. Manufactured according to technical regulations for compressed gases with TÜV certificate. Gas cylinder labelling in accordance with DIN EN 1089.

  • DILO - Gas Cylinders for Used Gas

    DILO - Gas Cylinders for Used Gas

    Used SF6 with a SO2 content of ≥ 250 ppmv. Manufactured according to technical regulations for compressed gases with TÜV certificate. Gas cylinder labelling in accordance with DIN EN 1089.

  • Filter Units - Pre-Filter and Separating Units

    On the assumption that contaminated or humid gas is in the circuit breaker we recommend the use of pre-filters between switchgear and service cart. Moisture, gaseous and dusty decomposition products as well as oil aerosols are adsorbed by special dry and particle filters during the recovery operation. Thus, service carts are protected effectively against contamination as most of the moisture and decomposition products are collected. Our pre-filter units are available as portable or mobile ve

  • Oil-Free SF6 Suction Pumps

    The mobile suction pump allows upgrading old SF6 maintenance devices. Thus it is possible to recover the SF6 gas from the gas compartment to a final vacuum of 1 mbar by connecting in series the mobile suction pump.

  • DILO - SF6 Leak Testing Units

  • DILO LeakScanner - Model SA - Atmospheric Test Chamber With Automatic Roller Shutter

    DILO LeakScanner - Model SA - Atmospheric Test Chamber With Automatic Roller Shutter

    With atmospheric test chambers it is not necessary to evacuate air before the test process. Test chambers of this construction type can be manufactured at significantly lower cost with a significantly larger volume than vacuum chambers. We build these chambers with a chamber volume of up to 50 m³ as standard. This allows for reliable testing of even larger units and assemblies.

  • DILO - SF6 Monitoring Devices

  • DILO - Model K091R65 and K091R67 - Electronic Bottle Scales

    DILO - Model K091R65 and K091R67 - Electronic Bottle Scales

    The electronic bottle scales allow quick and easy determination of the filling quantity of a gas bottle. The large weighing platform and the supporting chain provide additional stability of the gas bottle. The weight is indicated on the illuminated display which switches off automatically if the scales are not used for a certain time. Thanks to the tare function gas inputs and outputs can be quantified exactly. The bottle scales can be folded...

  • DILO - Model K091R54 - Weighing Scales

    DILO - Model K091R54 - Weighing Scales

    The weighing scales have been developed specially for large containers used for example in GIS production or in large substations. The weighing range of the device is up to 2,000 kg. The determined weight is indicated on the display immediately. The integrated serial interface is a special feature allowing data communication with other DILO devices. Thus, not only the weight can be read on the service cart, but the recovery process can also be stopped...

  • DILO - Model B195R01 and B195R02 - Weighing Unit for SF6 Monitoring Manager

    DILO - Model B195R01 and B195R02 - Weighing Unit for SF6 Monitoring Manager

    This weighing unit is a useful tool for the SF6 gas bottle management in connection with the „SF6 Monitoring Manager“, a specially developed database software. The quantity of SF6 stored in gas bottles is precisely determined by means of electronic scales, incoming and outgoing gas vessels are identified by means of the integrated barcode scanner. The required bar code labels can be printed on site with the optional label printer (only...

  • DILO - Model B195R30 - Operating Unit for SF6 Monitoring Manager Software

    DILO - Model B195R30 - Operating Unit for SF6 Monitoring Manager Software

    Monitoring system for connection to digital weighing scales and filling devices. This weighing unit is a useful tool for the stock management of SF6 cylinders and containers in connection with the 'SF6 Monitoring Manager' database software. The integrated interface allows the connection of the operating unit to all DILO weighing scales and gas refilling devices equipped with a serial interface for data exchange or monitoring. The device is portable...

  • SF6 Monitoring Devices - Mass Flow Measuring Systems

  • DILO - Model B152R41 / B152R41S15 and B152R51 - Mass Flow Measuring System

    DILO - Model B152R41 / B152R41S15 and B152R51 - Mass Flow Measuring System

    B152R41 / B152R41S15: Mass flow measuring system with an additional resettable, adding and subtracting counter. B152R51: Mass flow measuring system ( battery-operated with charge indicator). Battery operation enables an application independent of the power supply. With this device, gas monitoring is just that simple. Gas quantities which are filled in and recovered are registered and can be transferred to a computer. The system displays the current...

  • DILO - Model B152R90 / B152R90S15 & B152R91 / B152R91S15 - Mass Flow Measuring System

    DILO - Model B152R90 / B152R90S15 & B152R91 / B152R91S15 - Mass Flow Measuring System

    B152R90 / B152R90S15: Mass flow meter with automatic filling function. B152R91 / B152R91S15: Mass flow meter with automatic filling function with wireless data transmission. The unique combination of mass flow meter and filling device facilitates the SF6 gas monitoring considerably. This device does not only enable the registration of the quantities filled in, but allows the automatic filling of a gas compartment at the same time. Thus the operator...

  • SF6 Gas Measuring Devices

  • DILO - Model 3-035R-R - Multi-Functional Mirror-Analyser SF6 Device

    DILO - Model 3-035R-R - Multi-Functional Mirror-Analyser SF6 Device

    The Mirror-Analyser SF6 uses the physical dew point mirror measuring principle which is characterised by its high precision and utmost reliability in order to measure the moisture content. By cooling the integrated mirror the moisture content of the gas is determined by measuring the temperature depending on the condensation or icing of the mirror. The other parameters of SF6 quality are determined by measuring the speed of sound (SF6 volume...

  • DILO - Model B169R - SF6 Gas Monitoring System

    DILO - Model B169R - SF6 Gas Monitoring System

    The device is used to monitor and record the quality of the SF6 gas in a gas compartment. The following quality parameters can be determined with only one measurement: SF6 volume percentage (%). Moisture concentration (°C atmosphere, °C pressure, °F atmosphere, °F pressure, ppmv, ppmw). SO2-Concentration (ppmv).

  • DILO - Model 3-037-R001 - Electronic Moisture Measuring Device With Dew Point Indication

    DILO - Model 3-037-R001 - Electronic Moisture Measuring Device With Dew Point Indication

    Moisture is the most important criteria for the determination of the gas quality. This device has been designed specially for SF6 moisture measurements. It shows a higher resistance against contamination and SF6 decomposition products than conventional moisture sensors and even minimises the usual long time drifting. The integrated electronic flow meter supports the minimisation of the gas sample quantity and works independently of its position which...

  • DILO - Model 3-032-R... - Portable SO2 Measuring Device with LED Indication

    DILO - Model 3-032-R... - Portable SO2 Measuring Device with LED Indication

    For measurement of the SO2 concentration in gas mixtures. Before maintenance works are carried out it is absolutely necessary to know the gas quality. This special equipment allows precise measurement of SO2 in gas mixtures. Furthermore, this device is very resistant against contamination and SF6 decomposition products and is therefore a reliable instrument for each revision of circuit breakers.

  • DILO - Model 3-033-R200 - SF6-LeakSpy - SF6 Gas Detector

    DILO - Model 3-033-R200 - SF6-LeakSpy - SF6 Gas Detector

    The cordless battery-operated LEAKSPY SF6 precisely measures SF6 concentration in air by means of a non dispersive infrared sensor (NDIR sensor) and indicates the value on a graphic display in ppmv. The device allows precise localisation of leaks by searching the highest SF6 concentration. Thanks to the high accuracy and the low detection limit it is possible to carry out integral measurements as well as measurements for determination of leakage...

  • DILO - Model 3-033-R002 - SF6-LeakPointer - SF6 Leak Detector

    DILO - Model 3-033-R002 - SF6-LeakPointer - SF6 Leak Detector

    The cordless battery operated device measures in seven levels of sensitivity within a short response time. Even after the detection of large leaks the device returns to zero position quickly. The SF6 LeakPointer is easy to operate with one hand. Leakages can be easily detected via the clearly visible LED display or the audible signal (can be switched off). Continuous operation of the device is possible.

  • DILO - Model 3-026-R115 - SF6-Air Sensor

    DILO - Model 3-026-R115 - SF6-Air Sensor

    For monitoring the air of SF6 indoor plant in permanent operation. The device even detects smallest SF6 concentrations and displays the current measuring values permanently. For the operating personnel it is absolutely necessary to know that no radioactive source is used. Therefore no special measures must be taken during operation. The SF6 Air Sensor guarantees a quick reaction time. Furthermore, there is no cross sensitivity to moisture and...

  • DILO - Model 3-026-R114 - SF6 Network Monitor

    DILO - Model 3-026-R114 - SF6 Network Monitor

    The SF6 Network Monitor is the central control unit from up to five SF6 Air Sensors to be connected. Warning and alarm thresholds can be set for each SF6 Air Sensor. The plug-and-play operating concept makes the handling very comfortable. Measuring values can be stored and called on the 5.7' coloured touch screen, if necessary.

  • DILO - Model B178R01 - DensiControl DA - Density Monitor Testing Devices

    DILO - Model B178R01 - DensiControl DA - Density Monitor Testing Devices

    The F-gas regulation (EU) 517/2014 stipulates regular verification of density monitors installed in switchgear. The DensiControl DA allows quick checking to see whether the density monitor switching points are triggered in time. This device allows precise, quick and easy verification of the switching points. The density monitor type to be checked is selected in the data base and is then installed on the device with a quick clamping mechanism. After...

  • DILO - Model B178R51 - DensiControl IN - Density Monitor Testing Devices

    DILO - Model B178R51 - DensiControl IN - Density Monitor Testing Devices

    DensiControl IN with connecting kit and 6 m long measuring hose. The F-gas regulation (EU) 517/2014 stipulates regular verification of density monitors installed in switchgear. In combination with a DILO lock valve it is possible to quickly check whether the density monitor switching points are triggered in time without disassembling the density monitor. Thus, the DensiControl IN allows very quick, easy and precise verification of the switching points...

  • DILO - Model 3-027-R002 - SF6 Volume Percentage Measuring Device

    DILO - Model 3-027-R002 - SF6 Volume Percentage Measuring Device

    For measurement of the volume percentage in air and nitrogen mixtures. This device serves for measuring the gas purity necessary to maintain the dielectric property for arc quenching in circuit breakers. Thanks to the speed of sound measurement developed by DILO results are provided immediately. The microprocessor installed converts the values measured into the SF6 volume percentage. Easy rinsing after the measuring process - and the device can be...

  • Accessories for Measuring Devices

  • DILO - Model 3-826-R003 / R004 / R005 - Compressor Unit for SF6 Measuring Devices

    DILO - Model 3-826-R003 / R004 / R005 - Compressor Unit for SF6 Measuring Devices

    The test pressure for gas analysis in medium voltage switchgear is often too low. For this reason the compressor unit is needed to compress the gas to be measured so that there is sufficient pressure for the gas measuring devices connected downstream from the compressor unit. As the device is leak-tested there are no SF6 emissions. The oilfree compression avoids the SF6 test gas from being contaminated with oil mist. Any contamination of the measuring...

  • DILO - Model B151R95 - Discharge Gas Collecting Bag

    DILO - Model B151R95 - Discharge Gas Collecting Bag

    This bag is a simple and cost-effective system for collecting measuring gas in case it cannot be returned directly into the circuit breaker. Its handling is very easy: Connect the bag with the hose included in the scope of supply to the measuring device.

  • DILO - Model 3-1190-R... - Lock Valves for Density Monitors PN16 DN20

    DILO - Model 3-1190-R... - Lock Valves for Density Monitors PN16 DN20

    Density monitors can be verified directly at the gas compartment or disassembled for external tests without having to recover the gas from switchgear by means of these lock valves. The valve securely separates the assembled density monitor from the gas compartment. In combination with the Densi- Control IN (B178R51) density monitor testing device it is also possible to quickly and easily verify the density monitor switching points on switchgear...

  • DILO - Model 3-1150-R... - Lock Valve for Density Monitors PN16 DN20

    DILO - Model 3-1150-R... - Lock Valve for Density Monitors PN16 DN20

    Density monitors can be verified directly at the gas compartment or disassembled for external tests without having to recover the gas from switchgear by means of these lock valves. The valve securely separates the assembled density monitor from the gas compartment. In combination with the Densi-Control IN (B178R51) density monitor testing device it is also possible to quickly and easily verify the density monitor switching points on switchgear...

  • DILO - SF6 Valves & Couplings

  • DILO - Sealing Valves for Decades

    DILO - Sealing Valves for Decades

    DILO couplings allow a connection to be made by simply screwing the two coupling parts together. Before the metal to metal seal closes the pressure and vacuum tight coupling is sealed inside by means of an O-ring. When loosening the coupling parts again, the same O-ring prevents gas loss whilst the self seal valves close.

  • DILO - SF6 Solutions for GIS Production

    Automated production process with permanent monitoring of the SF6 quality requires intelligent and innovative SF6 gas handling to achieve the highest economic efficiency and exemplary environmental protection. We offer high-performance, customer-specific special equipment for GIS, GIL and GIT applications.

  • DILO - Stand Alone Devices

    DILO - Stand Alone Devices

    For the production of small quantities (insular production) we offer high performance stand alone units. Stand-alone unit with integrated gas monitoring system for venting, evacuation of air, SF6 filling or recovery of gas compartments. Error-proof operation via 7' touch panel.

  • DILO - Large Volume Storage Tanks

    DILO - Large Volume Storage Tanks

    For gaseous or liquid storage of SF6 gas. For the central gas stock we offer storage tanks for intermediate storage of large SF6 quantities available for gaseous storage to 25 bar and liquid storage to 50 bar.

  • DILO - Hall Piping

    DILO - Hall Piping

    DILO carries out the complete production area piping according to the customer's specification – from the first layout, material procurement, assembly up to the final approval. A temperature compensated pressure control of the factory piping is available as an option allowing immediate detection of leaks on the piping.

  • DILO - Special SF6 Solutions

  • DILO - Refrigeration Units for Gas Insulated Transformers (GIT) and Accelerator Plants

    DILO - Refrigeration Units for Gas Insulated Transformers (GIT) and Accelerator Plants

    For reliable continuous cooling. The essential advantage of our refrigeration units is that the cooling is carried out by means of water outside the transformer. This is to prevent the transformer from being damaged if leaks occur. The cooling systems can be connected to the gas insulated transformer directly and are optimally suited for continuous operation.

  • DILO - SF6 Gas Handling Units for Accelerators

    DILO - SF6 Gas Handling Units for Accelerators

    We also deliver custom-tailored solutions for the SF6 gas handling of electron accelerators. Compared to the 'normal' gas handling in the energy sector, larger SF6 gas volumes – usually several tons – have to be handled in the field of electron accelerators. Therefore, high-performance system components as well as large supply lines (up to DN 100) are needed, so that the gas volume can quickly and effectively be filled from the storage...

  • Alternative Gases - Service Carts

  • DILO - Model Mini Series C4/C5 - Professional Handling of Gas Mixtures

    DILO - Model Mini Series C4/C5 - Professional Handling of Gas Mixtures

    The MINI SERIES C4/C5 is perfectly suited for efficient gas handling of small gas compartments and gas recovery down to < 5 mbar.  It is specially designed for the handling of gas mixtures based on 3M Novec 4710 or 3M Novec 5110. The working pressures allow gaseous storage in order to prevent demixing. Thus, filling of the gas mixture from the gas compartment into a transport cylinder as well as the complete removal of the gas mixture from a...

  • DILO - Model C4-B093R30/C5-B093R30 - Professional Handling of Gas Mixtures

    DILO - Model C4-B093R30/C5-B093R30 - Professional Handling of Gas Mixtures

    C4-B093R30: Vacuum compressor unit for gas mixtures with 3M Novec 4710. Operating voltage: 220 - 240 V / 50 - 60 Hz alternating current. C5-B093R30: Vacuum compressor unit for gas mixtures with 3M Novec 5110 - Operating voltage: 220 - 240 V / 50 - 60 Hz alternating current. For recovery in conjunction with compressor only.

  • DILO - Portable Vacuum Pump Unit for the Evacuation of Air

    DILO - Portable Vacuum Pump Unit for the Evacuation of Air

    Technical data: Dimensions: Length 435 mm, Width 270 mm, Height 370 mm. Weight: 29 kg. Standard equipment: Vacuum pump for evacuation of air 16 m³/h (at 50 Hz) and 19 m³/h (at 60 Hz), final vacuum < 1 mbar. DILO couplings DN20. Ball valve or solenoid valve DN20. Digital vacuum indication (0 - 400 mbar). 3 m long electrical connecting cable. Operating manual.

  • DILO - Model C4/C5-B077R11 - Pre-Filter Unit (Pe 10 Bar)

    DILO - Model C4/C5-B077R11 - Pre-Filter Unit (Pe 10 Bar)

    For adsorption of moisture, solid and gaseous decomposition products. Technical data: Dimensions: Length 180 mm, Width 105 mm, Height 360 mm. Weight: 4 kg. Standard equipment: Dry filter. Particle filter. DILO couplings DN8. Operating manual.

  • DILO - Model C4/C5-G057R01 - Economy Series - Service Cart for Gas Mixtures

    DILO - Model C4/C5-G057R01 - Economy Series - Service Cart for Gas Mixtures

    This series has been specially developed for the emission-free handling of gas mixtures based on 3M Novec 4710 or 3M Novec 5110 and its specific requirements. The units are equipped with a temperature control of the compressor adapted to the mixed gas and allow gas recovery down to a final vacuum of < 1 mbar. The service carts make the handling of Alternative Gases simple and convenient. Thanks to the fully automated technology the basic functions...

  • DILO - Model C4/C5-G057R51 - Unit for Recovery of Gas Mixtures

    DILO - Model C4/C5-G057R51 - Unit for Recovery of Gas Mixtures

    This model range has been specially developed for the emission-free recovery of gas mixtures with 3M Novec 4710 or 3M Novec 5110 and its specific requirements and allows gas recovery down to a final vacuum of < 1 mbar. The devices are equipped with a compressor temperature control specially adapted to the gas mixtures. The maximum storage pressure is 100 bar (pe) and thus allows liquid storage of the gas mixture. The recovered gas quantity can be...

  • Alternative Gases - Measuring Devices

  • DILO - Model 3-033-R400 - Leakspy C4 for Gas Mixtures

    DILO - Model 3-033-R400 - Leakspy C4 for Gas Mixtures

    The cordless battery-operated LEAKSPY C4 precisely measures the 3M Novec 4710 concentration in air by means of a non-dispersive infrared sensor (NDIR sensor) and indicates the value on a graphic display in ppmv. The device allows precise localisation of leaks by searching the highest 3MTMNovecTM 4710 concentration. Thanks to the high accuracy and the low detection limit it is possible to carry out integral measurements as well as measurements for...

  • DILO - Model C4-Z1004R01/C5-Z1004R01 - Mixing Unit for the Handling of Gas Mixtures

    DILO - Model C4-Z1004R01/C5-Z1004R01 - Mixing Unit for the Handling of Gas Mixtures

    The mixing units have been specially developed for the handling of gas mixtures based on 3M Novec 4710 or 3M Novec 5110 and their specific requirements. A total of three gas components can be mixed. The gas mixture is circulated by the compressor to generate a homogenous mixture. Using the integrated compressor, the generated gas mixture can be filled directly into gas compartments or for transportation, stored into cylinders with up to 100 bar.

  • Alternative Gases - Accessories

  • DILO - Model C4/C5 Series - Couplings and Valves

    DILO - Model C4/C5 Series - Couplings and Valves

    C4/C5 series as safe connections to SF6-free gas compartments. For decades, DILO couplings and valves have proven themselves as safe connections in SF6-filled gas compartments. We also offer appropriate connections for connecting. SF6-free switchgear or electrical equipment, which are essential for safe and emission-free gas handling.

  • Industrial Gas Equipment

  • DILO - Gas Drying Unit

    DILO - Gas Drying Unit

    Optionally two circuits are available, depending on the existing connecting couplings on the gas compartment: Drying in circulation or drying by storing the gas in the internal storage vessel.

  • DILO Xenon - Recovery Unit

    DILO Xenon - Recovery Unit

    For the economic recovery of xenon from production plants. Special features/Process: Evacuation of the customer's test chamber. Filling of the chamber with xenon. After successful testing inside the chamber, the gas is recovered and stored into cylinders. Permanent monitoring of the gas quality by means of an O2 sensor. Reuse of the recovered gas if the gas quality complies with the customer’s specification or automatic supply of new gas in case...

  • DILO - Refrigeration for Cooling Gas-Filled Units in Continuous Operation

    DILO - Refrigeration for Cooling Gas-Filled Units in Continuous Operation

    Water-cooled heat exchanger. Cooling in continuous operation. Circulation pump for water cooling: 30 m³/min. Gas purification via particle filter (pore size 1 µm). Cooling capacity: ~ 45 kW. Operation via touch panel. Optional oilfree compressor 11.4 m³/h with 30 l dry filter for gas drying.

  • DILO - Gas Mixing Unit

    DILO - Gas Mixing Unit

    Unit for the precise production of gas mixtures. Accuracy of the gas mixtures to be produced up to ± 0.1 vol. %. A total of up to four different gases can be mixed. Mixing to the desired target weight or to the desired final pressure. Final vacuum after recovering the mixing vessel: < 1 mbar. Storage of the gas in adequate pressure vessels after the mixing process. Storage pressure up to 100 bar. Operation via 10” colour touch panel.

  • DILO - Construction of Gas Piping Systems

    DILO - Construction of Gas Piping Systems

    Integrated pressure monitoring for leak control. Special features: Complete realisation, ranging from the design to the commissioning. Piping systems can be realized in various materials, e.g. in copper or stainless steel. Integration into existing fabrication hall construction is possible. Use of gastight DILO unions without intermediate seal compound. Production in nominal diameters of up to DN150. High safety in the operation of gas piping through...

  • DILO - Gas Handling Unit

    DILO - Gas Handling Unit

    Stand-alone unit as customised solution for handling large gas quantities. Special features/Process: Evacuation of air. Filling of the gas compartment. Recovery of gas. Venting the gas compartment. Separated air and gas circuit to avoid the contamination of the gas with air.

  • DILO - Model Leaktracker - Localising Leak Testing Unit

    DILO - Model Leaktracker - Localising Leak Testing Unit

    For automated, localising leak testing of series components. Special features: Mobile or stationary measuring unit. Air as test medium with overpressure e. g. > 200 mbar. Linear or circular sensor guidance. Parallel operation of up to 32 sensors.

  • High Pressure Products

  • DILO - Weld-On Tube Unions

    DILO - Weld-On Tube Unions

    For permanent pipe connections: With weld-on ends on both sides. Available for tube diameters from DN3 up to DN50. Straight version, angles and Tee form. Temperature-resistant from -270 °C up to +650 °C (dependent on the material used). Available for pressures up to 1,000 bar on request.

  • DILO - Screw-In Tube Unions

    DILO - Screw-In Tube Unions

    For variable application: With weld-on end and screw-in thread. Available for tube diameters from DN3 up to DN50. Straight version, angles and Tee form. Metric, Whitworth or NPT thread. Temperature-resistant from -270 °C up to +650 °C (dependent on the material used). Available for pressures up to 1,000 bar on request.

  • DILO - Throttlefree Angle-Swivel Unions

    DILO - Throttlefree Angle-Swivel Unions

    For variable positioning of the weld end. With infinitely variable weld-on end. Available for tube diameters from DN3 up to DN40. Angles, L or Tee form. Metric, Whitworth or NPT thread. Temperature-resistant from -270 °C up to +500 °C (dependent on the material used).

  • DILO - Superheated Steam Unions

    DILO - Superheated Steam Unions

    Up to 650 °C operating temperature: Available as weld-on or screw-in version. For pressures up to PN 100. Metric or Whitworth thread. Available for tube diameters from DN3 up to DN40. Temperature-resistant up to +650 °C (dependent on the material used). Three-part union consisting of weld-on stub, clamping nut and  weld-on thread stub or screw-in stub.

  • DILO - Manual Blocking Valves and Non-Return Valves

    DILO - Manual Blocking Valves and Non-Return Valves

    For medium flow regulation: Robust, durable version. Delivery complete with DILO connecting parts. Temperature range of non-return valves -20 °C to +70 °C (media-dependent). Application range of blocking valves from -270 °C up to +400 °C. Available in DIN 1.0460 und 1.4571 materials.

  • DILO - Gauge Connection Unions

    DILO - Gauge Connection Unions

    For reliable connection of gauges: Available in pressure ranges of PN 100, 200 and 320 bar. Suitable for G1/2' gauge threads and all commercial types. Available in DN3 to DN10 tube diameters. Other thread diameters are available on request.

  • DILO - Blanking Disks for Isolating Pipes

    DILO - Blanking Disks for Isolating Pipes

    For assembly between tongue and groove part. For all types and pressure ranges. Available bored out for flow restriction. Range of application from -270 °C up to +650 °C dependent on the material used.

  • DILO - Special Tube Unions

    DILO - Special Tube Unions

    For customer-specific applications: Components are available in different materials. Chamfered fittings to adapt to different pipe and weld-on stub wall thickness. Double stubs for other connecting options are available.

  • DILO - Tube Unions

    DILO - Tube Unions

    DILO tube unions require no preliminary assemblyor any special tools. Determine tube lengths exactly, cut off square, remove burrs and chamfer tube edges as per DIN EN ISO 9692-1. The only point requiring attention is to ensure that welded-in unions are in proper alignment. Provided the above instructions are observed assembly is simple and time-saving. On the other hand too short or unaligned tubes lead to extra work.

  • DILO - High Pressure Tube Unions

    DILO - High Pressure Tube Unions

    The pressure stage table for DILO high pressure tube unions indicates the admissible operating pressure (bar) as a function of the operating temperature (°C).
