Iotronic Elektrogerätebau GmbH products

Process analyzers with touchscreen for alkalinity (+m-value) and forcarbonate hardness measurementThe AQUACON +m10/+20/CH10/CH20process analyzers consist of a control unit withtouchscreen and an analysis unit with measuring chamber, valve, dosing pumps and allrequired tube connections

The AQUACON CL02 process analyzer can be used for the monitoring and control of the chlorine dioxide concentration in water. Measurement principle is the determination of chlorine dioxide by dosing a special developed reagent to a buffered water sample until the sample changes its colour (titration). The colour change is detected by a monochromatic photometric detection system. The measurement is selective (no influence from other chlorine species in drinking water relevant concentrations).

The AQUACON CL2 and AQUACON CHLOR process photometers can be used for the monitoring and control of the chlorine concentration in water. Measurement principle is the photometric determination of chlorine by dosing a special reagent based on N,N-Diethyl-p-phenylendiaminsulfat (DPD) to a buffered water sample. The wine-red colour formed as a result of the reaction is detected by a monochromatic photometric detection system. The AQUACON CL2 determines the concentration of free chlorine or of total chlorine. The AQUACON CHLOR determines the concentration of free chlorine and of total/bounded chlorine.

AQUACON LF is the first process conductivity meter type tested by TÜV Nord,suitable for measurement of conductivity in salt-free boiler feed water. Developed particular for this application, AQUACON LF meets the qualification of: VdTÜV-leaflet „Wasserüberwachung 100“ for equipment with safety function in the meaning of pressure equipment directive 97/23/EG date 29.march 1997.

The AQUACON F10/F20/F30 process titrators can be used for the monitoring and control of the fluoride concentration in water. Measurement principle is the determination of dissolved fluoride with a special developed ion-sensitive electrode (ISE). Therefore, two reagents (TISAB and standard solution) are added to the water sample in the measurement chamber of the analyzer (standard addition method with titration). Main applications for the ion-sensitive analyzers are the monitoring of the fluoride concentration in process water and drinking water.

The AQUACON N2H4 process photometer can be used for the monitoring and control of the hydrazine concentration in water. Measurement principle is the photometric determination of hydrazine by forming of an Azine compound by reaction with 4-(Dimethylamine)-benzaldehyde.

The AQUACON Fe10 and Fe20 process photometers can be used for the monitoring and control of the dissolved iron (Fe2+, Fe3*) concentration in water. Measurement principle is the photometric determination of iron by forming a Pyridyl-Triazine compley (AQUACON Fe10) or by forming a 1,10-Phenanthrolin complex (AQUACON Fe20).

Process analyzers with touchscreen for alkalinity (+m-value) and for carbonate hardness measurement. The AQUACON +m10/+20/CH10/CH20 process analyzers consist of a control unit with touchscreen and an analysis unit with measuring chamber, valve, dosing pumps and all required tube connections.

The AQUACON Ni10 process photometer can be used for the monitoring and control of the dissolved nickel concentration in water. Measurement principle is the photometric determination of nickel by forming a red complex after the reaction with Dimethylglyoxim.

The AQUACON PH80 process photometer can be used for the monitoring and control of the pH value. Measurement principle is the photometric detection of the color formed after adding a specific indicator reagent to a water sample.
