Komptech Americas, LLC products

Stationary Single-Shaft Shredder for Pre-Shredding.

Stationary Dual-Shaft Shredder for Wood and Green Waste.

Multistar Stationary Star Screen.

Multistar 3SE Stationary Star Screen.

The Flowerdisc represents a further technology for the screening of pre-shredded commercial, bulky and bio-waste, a technology which combines high throughput, selectivity and resistance to contamination. Material is transported by shafts with rugged steel discs working on the disc screen principle. Movable jacketed pipes positioned between the discs prevent seizures and blockages by contraries.

The stationary Hurrikan windsifter-system allows effective cleaning of over-sized screened particles. The unit is extremely compact for a windsifter and can be integrated easily into a system chain. The patented „pressure-suction“ principle is used to separate plastic with a high degree of selectivity. In the second step, the lightweight material is drawn off by a powerful suction blower. The suction performance is adjustable to material by variation of blower speed, blower distance and vent flaps. The quality of the recyclable oversized particles can be improved yet further by using magnet separation and a stone trap.

The Ballistor separates out usable fractions from waste and potential recyclables. By combining ballistic separation with screening, in just one pass-through the material stream is separated to the criteria 3/2-dimensional, rolling-cubic-rigid/flat-soft-narrow, and particle size. This means that high-caloric fractions can be separated out of commercial or household waste and further processed into RDF in one operation. Other methods like screening followed by windsifting involve a conveyor and take substantially more space and energy. The Ballistor’s long-life components, readily replaceable wear elements, and excellent maintenance access further reduce operating costs. With a choice of separation into three or four fractions, five sizes and many options, the Ballistor separator can be configured to suit the application.

The Hurrifex combines a stone separator and wind sifter in a single machine. This makes it possible to clean compost and biomass fractions of stones and light materials - primarily plastic film - in one pass. Easily adjustable separation parameters give the Hurrifex a wide range of applications, and a separation efficiency of more than 90 percent. All components are electrically powered, from grid power or with the on-board diesel generator. Large doors provide full access to all maintenance positions. Biomass processors profit from better customer demand for their fuels and higher sale prices.
