Rotork plc

271 products found

Rotork plc Products

  • Electric Actuators and Control Systems

  • Rotork - Model CK - Standard Electric Actuators

    Rotork - Model CK - Standard Electric Actuators

    Comprising electric motor, drive gearing, independent handwheel drive, torque and position limit control & indication with plug and socket field wiring connection. The CK range provides the right solution for users with centralised motor control centres or for high temperature and sustained vibration applications. CK - Standard isolating duty actuator. CKR - Standard modulating duty actuator.

  • Rotork - Master Station

    Rotork - Master Station

    The Rotork Master Station provides the high integrity link from the Distributed Control System (DCS) to the devices in the field. It comes complete with a large touch screen interface to allow operators and engineers to see exactly what is happening to the system and the field devices at any time. A hot standby Rotork Master Station allows for continued availability of the system in the event of a component failure. Host ports allow...

  • Pakscan - Classic Field Network Add In Module (AIM)

    Pakscan - Classic Field Network Add In Module (AIM)

    Proven Control System: The Pakscan™ Classic redundant loop network has been the network of choice for actuator control for over 30 years. Using robust current loop technology, up to 20 km loop lengths and 240 field devices are possible.

  • Rotork - Model CK Atronik - Electric Actuators

    Rotork - Model CK Atronik - Electric Actuators

    The Atronik control module adds an intermediate level integral solution to the modular CK range. CKA - Atronik isolating duty actuator. CKRA - Atronik modulating duty actuator. It offers modest control and feedback, and optimises the integral starter approach to offer simplified electronics, creating a robust control package for CK actuators.

  • Rotork - Model IQM - Multi-Turn Modulating Electric Actuators

    Rotork - Model IQM - Multi-Turn Modulating Electric Actuators

    The modulating version of the IQ 3-phase electric actuator has a solid state reversing starter in place of the electro mechanical contactors. It features fast-response remote control circuits for rapid control. To optimise positional control, the solid state starter also adds an electronic motor ‘brake' feature.

  • Rotork - Model ExCos/ExBin - HVAC Explosionproof Sensors and Switches

    Rotork - Model ExCos/ExBin - HVAC Explosionproof Sensors and Switches

    ExCos analogue sensors and ExBin binary switches are designed for direct use in hazardous locations. No additional modules in the panel required. No intrinsically safe wiring required. All parameters adjustable on site without additional tools or measuring devices. Sensors and switches for pressure, differential pressure, temperature and humidity available, Explosionproof design for all gases, mists, vapours and dust.

  • Rotork - Model ROM - Electric Actuators

    Rotork - Model ROM - Electric Actuators

    ROM actuators provide quiet and reliable operation for all kinds of small ball valves and butterfly valves, as well as dampers and ventilation louvres. They provide local indication and manual override options together with a wide range of voltages.

  • Modbus Field Network Add In Module (AIM)

    Modbus Field Network Add In Module (AIM)

    Industry Standard Networking: In addition to the Rotork designed network option, the Rotork Master Station also offers a Modbus® network all the way down to the field devices. The Modbus® RTU network is an RS-485 voltage based network in accordance with the Modbus® serial standard. Network baud rate is selectable up to 115 kbps, distance dependant, and network termination can be achieved within the actuator.

  • Rotork - Model AH Series - High-Cycle Actuator

    Rotork - Model AH Series - High-Cycle Actuator

    The Rotork AH Series high-cycle actuator is ideal for the demanding service found under precipitators on the ash hopper flap gates. The totally-enclose design eliminates the high maintenance cylinder or low-pressure canister actuators.

  • Rotork - Model CT Series - Linear Damper Drive

    Rotork - Model CT Series - Linear Damper Drive

    The CT Series linear damper drive was designed specifically for fuel air and auxiliary air applications on CE / Alstom / T-fired / Corner-fired boilers. The CT Series provides excellent and efficient control of the Secondary Air within the windbox and will withstand the extreme heat and vibration common in this application. Effective windbox control will reduce NOx and minimise carbon monoxide (CO) associated with poor fuel-air mixing and will...

  • Rotork - Model CK Modularity - Electric Actuators

    Rotork - Model CK Modularity - Electric Actuators

    The modular design concept enables quick product configuration from stock to customer specification with a short lead time. Module combination enables Rotork to provide the optimal solution for the wide variety of customer applications. This benefits both suppliers and end users of CK range actuators.

  • Rotork - Model ROMpak - Electric Actuators

    Rotork - Model ROMpak - Electric Actuators

    The ROM range of actuators can be enhanced with the addition of a self-contained control package to create a ROMpak actuator. This adds local controls, status indication relays, isolated control circuits and support for Rotork control options such as Folomatic, Pakscan™ and other bus systems.

  • Rotork - Model ExReg - HVAC Explosionproof Control Systems

    Rotork - Model ExReg - HVAC Explosionproof Control Systems

    The ExReg controller system has been designed for use in Ex areas for all gases, mists, vapours and dust. In combination with Ex-Max actuators it is a closed loop control system for volume flow control (VAV, CAV), pressure, temperature and humidity.

  • Rotork - Model IQD - Multi-Turn Direct Current Electric Actuators

    Rotork - Model IQD - Multi-Turn Direct Current Electric Actuators

    IQD actuators are direct current powered versions of IQ actuators. Direct torque range 11 Nm to 305 Nm (8 lbf.ft to 225 lbf.ft). Voltage ranges available are 24, 48 and 110 VDC. With the addition of second stage gearboxes, DC multi-turn output torque up to 1,500 Nm (1,106 lbf.ft) and quarter-turn up to 132,000 Nm (97,358 lbf.ft) are available.

  • Rotork - Model CK - Manual Operation Electric Actuators

    Rotork - Model CK - Manual Operation Electric Actuators

    Simple Engagement. Manual override on CK range actuators utilises the proven Rotork clutch design developed over the past 60 years. Handwheel operation is achieved through a lever mechanism that declutches the motor drive train and engages the geared handwheel drive train. Motor operation will automatically disengage handwheel mode if the lever remains in the rest position.

  • Rotork - Model IQH - High Speed Electric Actuators

    Rotork - Model IQH - High Speed Electric Actuators

    Based on the multi-turn IQ actuator, IQH provides a range of high output speed actuators with integral epicyclic gearing. Gearing is optimised to be irreversible and provide a self-locking function for the valve. IQH actuators have been developed for diverter valves in meter prover applications that require fast operation with positive seating and zero backdriving.

  • Rotork - Fire Protection Systems and Solutions

    Rotork - Fire Protection Systems and Solutions

    Rotork has the experience, know-how and product range to deliver virtually any actuation solution. Rotork products have long been chosen for their reliability and performance. Whilst these proven characteristics are certain under normal operating conditions, there are conditions that not even a standard Rotork actuator can operate in fire.

  • Rotork - Model IQT - DC Electric Actuators

    Rotork - Model IQT - DC Electric Actuators

    IQT part-turn 3-phase, 1-phase and DC electric actuators are designed for isolation or regulation duties (S2 & S3/Class A & B) of up to 1,200 starts per hour. Direct torque output range from 50 Nm to 3,000 Nm (37 lbf.ft to 2,214 lbf.ft).

  • Rotork - Model CK - Switch Mechanism Electric Actuators

    Rotork - Model CK - Switch Mechanism Electric Actuators

    Mechanical Switch Mechanism (MSM). Instantaneous position and torque are sensed mechanically and IP67 rated micro switches provide end of travel indication as well as torque trip indication. The end of travel torque trip and position limits for both directions require intrusive mechanical configuration.

  • Rotork - Model IQT - Part-turn Battery Backup

    Rotork - Model IQT - Part-turn Battery Backup

    The IQT Battery Backup actuator provides valve fail-safe operation by utilising power from a battery source during AC supply mains failure. Under normal supply conditions the actuator operates from the site AC electrical supply. On loss of this supply the actuator automatically switches over to receive power from a 24 VDC supply allowing control of the valve to the...

  • Model IQ 3-Phase - 3-Phase High Speed Electric Actuators

    Model IQ 3-Phase - 3-Phase High Speed Electric Actuators

    IQ 3-phase electric actuators for isolating, regulating or inching duties (S2 & S3 / Class A & B) of up to 60 starts / hour. Direct torque output range from 10 to 3,000 Nm (7 to 2,200 lbf.ft). With second stage gearboxes, multi-turn output torque up to 44,000 Nm (32,452 lbf.ft) and part-turn up to 826,888 Nm (609,881 lbf.ft).

  • Control Systems

    Control Systems

    Control component packages are a part of any actuator / valve installation. Rotork has extensive experience in the design and assembly of all types of fluid power control systems to satisfy any customer requirement for on / off, modulating or ESD (emergency shutdown) service. Packages can be mounted on a panel or in a cabinet and mounted either on the actuator or at a remote location. Rotork offers components from all leading industry suppliers as well...

  • Rotork - RHS - Remote Hand Station

    Rotork - RHS - Remote Hand Station

    The Remote Hand Station enables duplicated operation, interrogation and configuration of the latest SI actuators. For use when the actuator is located in a hazardous or inaccessible location.

  • Gearboxes and Gear Operators

  • Rotork - Model QTW150 - Manual Quarter-Turn Gear Operators

    Rotork - Model QTW150 - Manual Quarter-Turn Gear Operators

    The QTW150 manual gearbox has been designed with simplicity in mind, resulting in a robust design with manufacturing optimised to deliver reliability and consistent performance. The QTW150’s simple, rugged construction makes it an ideal choice for quarter-turn valve applications.

  • Mounting Kits - Ball, Butterfly and Plug Valve Kits

    Mounting Kits - Ball, Butterfly and Plug Valve Kits

    A complete range of precision CNC machined stainless steel or carbon steel mounting kits. With open or closed construction, mounting kits are engineered from certified material, individually bagged and labelled ready for assembly.

  • Rotork - Multi-Turn Gearboxes

    Rotork - Multi-Turn Gearboxes

    Rotork has a wide range of multi-turn bevel/spur gearboxes which can be used for the most demanding manual and motorised applications for globe valves, gate valves and sluice gates. The output torque ranges up to 46,100 Nm and thrust range up to 4,350 kN. The multi-turn output gearboxes are available in various sizes and combinations with ratios from 1:1 to 360:1 and the majority of them can be used in all types of environment. Various options are...

  • Roto Hammer - Chain Bar Wrench

    Roto Hammer - Chain Bar Wrench

    The Roto Hammer Chain Bar Wrench provides an ideal solution for remote actuation of ball, butterfly, plug and other partial turn valves. When ordering, please provide length of chain required and dimensions so the chain bar wrench can be custom fit to your valve.

  • Roto Wheel - Model C Series - With RCK Safety Cable Kit

    Roto Wheel - Model C Series - With RCK Safety Cable Kit

    The Roto Wheel combines two critical components for safe and dependable suspended valve operation: our Roto Hammer Chainwheel complete with the addition of a fitted, factory installed retaining cable safety kit (RCK). Simplify the ordering and installation process by purchasing a Roto Wheel (which combines our Chainwheels with the popular RCK safety kits) or buy the Chainwheel and RCK separately and install in the field. The Roto Wheel is available in...

  • Roto Wheel - Model CL Series - RCK Safety Cable Kit

    Roto Wheel - Model CL Series - RCK Safety Cable Kit

    The Roto Wheel combines two critical components for safe and dependable suspended valve operation: our Roto Hammer Chainwheel complete with the addition of a fitted, factory installed retaining cable safety kit (RCK). Simplify the ordering and installation process by purchasing a Roto Wheel (which combines our Chainwheels with the popular RCK safety kits) or buy the Chainwheel and RCK separately and install in the field. The Roto Wheel is available in...

  • Roto Hammer - Chain Storage Bucket

    Roto Hammer - Chain Storage Bucket

    The Chucket Chain Storage Bucket holds overhead chain within easy reach and frees the pathway beneath, eliminating the safety hazard and hassle presented by suspended chain. The Chuckout combines the chain storage and safety features of the Chucket with an added Lockout/Tagout feature to prevent unauthorized access or operation of the valve.

  • Roto Hammer - Model CL Series - Chainwheel

    Roto Hammer - Model CL Series - Chainwheel

    The Roto Hammer CL Series Chainwheel can be installed in minutes and provides an easy, inexpensive way to ensure employee safety and effective valve operation. Opening and closing valves becomes as easy as standing at ground level and simply pulling the chain to operate the chainwheel above.

  • Rotork - Direct Mount Chainwheel

    Rotork - Direct Mount Chainwheel

    Direct Mount Chain Wheels mount directly onto the gearbox input shaft by means of a pin or coupling and are suitable for use with every gearbox range in our product offering.

  • Rotork - Extension Spindles

    Rotork - Extension Spindles

    Remote actuator mounting can be achieved using valve extension spindles or pedestal adaptors. Lengths can be from 500 mm to 8 metres, (20' to 300') in stainless steel or carbon steel.

  • Rotork - Model 242 - Quarter Turn Worm Gear Operators

    Rotork - Model 242 - Quarter Turn Worm Gear Operators

    The 242 range has been designed to optimise robustness and durability, whilst minimising non-structural mass and reducing the overall gearbox envelope by using the latest lean engineering principles and analytical design tools. The 242 series is based on the design and quality of the FB series which was designed to meet strict specifications. The 242’s simple, rugged construction makes it the gearbox of choice for low torque manual applications....

  • Rotork - Model IB - Multi-Turn Bevel Gearboxes

    Rotork - Model IB - Multi-Turn Bevel Gearboxes

    Rotork Series IB operators are multi-turn (rotary) devices intended for the operation of gate, globe, sluice and penstock valves. These gearboxes are suitable for the most demanding motorised applications.

  • Rotork - Model FB - Quarter-Turn Fire Protection

    Rotork - Model FB - Quarter-Turn Fire Protection

    Quarter-turn cast iron gearbox suitable for use with fire protection (i.e. sprinkler) systems, includes limit switches to be incorporated into a supervisory electrical circuit. Designed and tested specifically to meet UL1091 specification and FM1112 approval.

  • Rotork - Stainless Steel and Powder Coated Handwheels

    Rotork - Stainless Steel and Powder Coated Handwheels

    125 mm to 2000 mm (5' to 80') diameter. Stainless steel or powder coated. Keyed, pinned or square drive. Fabricated or pressed design. Oval or round designs for small valves. Optional open and closed indication marking, locking flange, handle, specials, galvanised finish, rotating handle, flat or dished.

  • Roto Hammer - Model E Series - Chainwheel

    Roto Hammer - Model E Series - Chainwheel

    The Roto Hammer E Series Direct-Mount Chainwheel is designed to provide a truly custom fit. Instead of clamping on to the existing handwheel, the E Series mounts directly to the valve stem and replaces the handwheel. This eliminates the need for multiple clamps and hardware sets and provides a more streamlined, secure fitting of the chainwheel to the valve. The E Series can be bored to customer specifications or shipped solid for machining by the...

  • Roto Hammer - Handwheels

    Roto Hammer - Handwheels

    Replacement handwheels can be ordered blank or custom fitted. If fitted, dimensional information is required.

  • Roto Wheel - Model E Series - RCK Safety Cable Kit

    Roto Wheel - Model E Series - RCK Safety Cable Kit

    The Roto Wheel combines two critical components for safe and dependable suspended valve operation: our Roto Hammer Chainwheel complete with the addition of a fitted, factory installed retaining cable safety kit (RCK). Simplify the ordering and installation process by purchasing a Roto Wheel (which combines our Chainwheels with the popular RCK safety kits) or buy the Chainwheel and RCK separately and install in the field. The Roto Wheel is available in...

  • Mastergear - Stainless Steel Bevel Gear Operators

    Mastergear - Stainless Steel Bevel Gear Operators

    Heavy-duty stainless steel 316 housing multi-turn gearboxes suitable for the most demanding manual and motorised applications. Suitable for cast and fabricated sluice gates, gate valves, globe and pinch valves.

  • Roto Wheel - Model M Series - RCK Safety Cable Kit

    Roto Wheel - Model M Series - RCK Safety Cable Kit

    The Roto Wheel combines two critical components for safe and dependable suspended valve operation: our Roto Hammer Chainwheel complete with the addition of a fitted, factory installed retaining cable safety kit (RCK). Simplify the ordering and installation process by purchasing a Roto Wheel (which combines our Chainwheels with the popular RCK safety kits) or buy the Chainwheel and RCK separately and install in the field. The Roto Wheel is available in...

  • Rotork - Model RCK - Safety Cable Kits

    Rotork - Model RCK - Safety Cable Kits

    Product Features: Provides an extra level of safety if the chainwheel should come unattached from the valve and fall. 3 sizes to fit the complete line up of Roto Hammer Chainwheels (CL, C, E & M Series) - Unit comes complete with - stainless steel cable, clamps and stainless steel shackle (1/4 and 5/16 only). RCK Safety Cable Kits are sold separately or come factory installed as part of a Roto Safety Wheel Unit.

  • Roto Hammer - Model M Series - Hammer Blow Impact Actuator Chainwheel

    Roto Hammer - Model M Series - Hammer Blow Impact Actuator Chainwheel

    Under certain conditions, manually operated valves can be difficult to open and close. The valve may stick, freeze, or be used so rarely that its internal parts become fused. In addition, large valves are often difficult to operate when using a standard chainwheel. In answer to these problems, Roto Hammer offers the M Series Hammer Blow Impact Actuator. The Hammer Blow mimics the motion of a hammer striking an anvil and delivers a quick, measured blow...

  • Rotork - Model IB-AWWA C560 and C561 - Multi-Turn Operators

    Rotork - Model IB-AWWA C560 and C561 - Multi-Turn Operators

    The IB AWWA C560 and C561 series of multi-turn operators are suitable for manual actuation of AWWA C560 cast iron gate valves and C561 fabricated stainless steel gate valves. Designed with AWWA C560 and C561 specifications in mind, they are manufactured from high quality and reliable materials.

  • Rotork - Lever Arm Range for Damper Operation

    Rotork - Lever Arm Range for Damper Operation

    Lever arms for damper operation. Used on dampers to transfer the 90 degree operation from the worm gearbox to the damper spindle. This is an optional feature on all IW and MTW ranges of worm gearboxes.

  • Model IS - Manual Multi-Turn Spur Gearbox

    Model IS - Manual Multi-Turn Spur Gearbox

    Rotork Gears Series IS operators are Multi-turn (rotary) devices intended for the operation of gate, globe, sluice and penstock valves. These gearboxes are suitable for manual and motorised applications.

  • Roto Hammer - Model M Series - Clamp-On Impact (Hammer Blow) Actuator

    Roto Hammer - Model M Series - Clamp-On Impact (Hammer Blow) Actuator

    Under certain conditions, manually operated valves can be difficult to open and close. The valve may stick, freeze, or be used so rarely that its internal parts become fused. In addition, large valves are often difficult to operate when using a standard chainwheel. In answer to these problems, Roto Hammer offers the M Series Hammer Blow Impact Actuator. The Hammer Blow mimics the motion of a hammer striking an anvil and delivers a quick, measured blow...

  • Roto Hammer - Replacement Parts

    Roto Hammer - Replacement Parts

    Available replacement parts: Chain Guide. Set Collar. Anvil. CL Series Clamp Set. C Series Clamp Set. M Series Clamp Set.

  • Roto Hammer - Right Angle Gearbox

    Roto Hammer - Right Angle Gearbox

    The Roto Hammer Right Angle Gearbox is designed for applications where 90 degree direction change is required, from vertical to horizontal or vice versa. The gearbox can be used in conjunction with Roto Hammer Valve Extensions, Handwheels, and Chainwheels. It is a 1:1 ratio gearbox.

  • Roto Hammer - Model M Series - Direct-Mount Impact (Hammer Blow) Actuator

    Roto Hammer - Model M Series - Direct-Mount Impact (Hammer Blow) Actuator

    Under certain conditions, manually operated valves can be difficult to open and close. The valve may stick, freeze, or be used so rarely that its internal parts become fused. In addition, large valves are often difficult to operate when using a standard chainwheel. In answer to these problems, Roto Hammer offers the M Series Hammer Blow Impact Actuator. The Hammer Blow mimics the motion of a hammer striking an anvil and delivers a quick, measured blow...

  • Rotork - Model BR Series - Quarter-Turn Manual Gearboxes

    Rotork - Model BR Series - Quarter-Turn Manual Gearboxes

    The BR series gear operators are manufactured from high quality cast aluminium bronze and stainless steel materialsand designed for extended life operation of valves in corrosive man hole and vault steam distribution environments where road salts, standing water and elevated temperatures are common.

  • Rotork - Model DSIR Range - Dual Speed Input Reducer

    Rotork - Model DSIR Range - Dual Speed Input Reducer

    The Dual Speed Input Reducer is used to reduce the number of input turns required, and therefore the operating time, on manual gearbox applications. It can be used with any manual gearbox which can be fitted with an F14 or FA14 input flange.

  • Roto Hammer - Galvanised Chainwheels

    Roto Hammer - Galvanised Chainwheels

    Especially harsh operating environments sometimes necessitate an extra level of protection for chainwheels. Many chainwheels are used in the petrochemical industry, where they are exposed to chemicals, extreme temperature or humidity. In such cases, we offer galvanized chainwheels to extend the life of the product in corrosive environments.

  • Roto Hammer - Roto Link and Lock Link Chain

    Roto Hammer - Roto Link and Lock Link Chain

    The Roto Link is a one piece, stainless steel, universal link designed to connect loose ends of Lock Link Chain when used in conjunction with our Roto Hammer Chainwheel Actuators. This prevents the hassle of cutting and twisting chain to close the loop. Simple installation can be accomplished with either vise-grips or pliers used to close the open ends around the next link of chain. Roto Links are made of T302 annealed stainless steel for its...

  • Roto Hammer - Valve Stem Extensions

    Roto Hammer - Valve Stem Extensions

    Regardless of the distance between points, elevations, directional flows and space constraints, we can engineer a Roto Hammer valve operation system that will work for you. No company can afford downtime, and with our Custom Solutions for valves, you’ll be back up and running sooner.

  • Roto Hammer - Stainless Steel Chainwheels

    Roto Hammer - Stainless Steel Chainwheels

    Especially harsh operating environments sometimes necessitate an extra level of protection for chainwheels. Many chain wheels are used in the petrochemical industry, where they are exposed to chemicals, extreme temperature or humidity. In such cases, we offer stainless steel chainwheels to extend the life of the product in corrosive environments.

  • Rotork - Model HOB/MPR - Bevel Gear Operators

    Rotork - Model HOB/MPR - Bevel Gear Operators

    Hand operated bevel gears suited for sluice gates, gate, and globe valves. Torque range up to 8,018 Nm (5,914 lbf.ft). Thrust range up to 1,557 kN (350,028 lbf). 12 sizes. Ratios from 2:1 to 81:1.

  • Rotork - AB - Quarter-Turn Manual Gearbox

    Rotork - AB - Quarter-Turn Manual Gearbox

    The AB range of quarter-turn operators have a cast iron housing and are intended for applications in chemical, power, waterworks, HVAC and most general industrial applications.

  • Rotork - Model HOS/MPR - Hand Operated Spur Gear Operators

    Rotork - Model HOS/MPR - Hand Operated Spur Gear Operators

    The HOS/MPR gear operators are manufactured from high quality materials and life tested ensuring that maximum performance, quality and reliability are consistently maintained. Operating temperature normally ranges from -40 ºC to 120 ºC, although other temperature ranges are available on request.

  • Roto Hammer - Custom Painted Chainwheels

    Roto Hammer - Custom Painted Chainwheels

    Roto Hammer Chainwheels are primed in the trademark Roto Hammer blue colour. However, we understand that some customers prefer a custom colour to match their facilities. In these situations, we are happy to custom paint any of our chainwheels to match a customer specified colour. Please contact us for information on pricing and lead time for custom painted wheels.

  • Rotork - Model ABAW-AWWA C504 and C517 - Manual Worm Gear

    Rotork - Model ABAW-AWWA C504 and C517 - Manual Worm Gear

    The ABAW AWWA C504 & C517 worm gear operators are suitable for manual actuation of AWWA C504 butterfly valves and C517 plug valves. They are designed to meet or exceed all aspects of AWWA C504 & C517 specifications and are manufactured from high quality and reliable materials. Overload and life tests reports are available upon request. All Rotork Gears actuators are made to ISO 9001 standards.

  • Rotork - Model IB/AS - Gearbox Combinations

    Rotork - Model IB/AS - Gearbox Combinations

    Rotork Gears Series IB/AS Combination operators are Multi-turn devices intended for the operation of gate, globe, sluice and penstock valves. These gearboxes are suitable for manual and motorised applications.
