Sabio Environmental products

The Model 6030 Ozone Analyzer provides an accurate and convenient means of measuring low levels of ozone in ambient air.

The Model 6050 CO Analyzer provides an accurate and convenient means of measuring low levels of Carbon Monoxide in ambient air. Principle of IR Analysis - Gas Filter Correlation. Advanced, easy to use, menu-driven software allows access to sample conditions and diagnostics and the strip chart feature allows the user to view a time series plot for CO readings. The 6050 Analyzer offers a bright color display, data logging capability and advanced communications via Ethernet, USB and RS-232.

The Model 6020 SO2 Analyzer provides an accurate and convenient means of measuring low levels of Sulfur Dioxide in ambient air. The Model 6020 measures sulfur dioxide by detecting the fluorescence of SO2 when exposed to ultraviolet (UV) radiation at wavelengths near 214 nm. The SO2 molecule fluoresces (reradiates) at longer wavelengths of approximately 360 nm, which is detected and measured by a photomultiplier tube (PMT). Narrow band optical filters are used to separate the 215 nm excitation light from the 360 nm fluorescing light. The Model 6020 consists of a sample inlet, hydrocarbon scrubber (kicker), optics, UV lamp, reaction chamber, PMT, UV detector, and associated electronics.

The Model 6040 NOx Analyzer provides an accurate and convenient means of measuring low levels of Nitrogen Oxides in ambient air. Principle of Analysis - Chemiluminescence Method Advanced, easy to use, menu-driven software allows access to sample conditions and diagnostics and the strip chart feature allows the user to view a time series plot for NO, NO2, NOx readings. The 6040 Analyzer offers a bright color display, data logging capability and advanced communications via Ethernet, USB and RS-232.

The Model 6060 UV TRS Analyzer provides accurate measurement of TRS (Total Reduced Sulfur) or TS (Total Sulfur) gas in air or low source levels from industrial processes. The Model 6060 TRS analyzer uses the same optical bench as the Model 6020 UV Sulfur Dioxide analyzer. An efficient external TRS oxidizer/converter thermally converts all sulfur gases to SO2. SO2 (Sulfur Dioxide) gas that may be present in the sample gas passes through the TRS converter unaffected. TRS and SO2 combined in the sample gas is called TS. If only TRS gas is the gas of interest, an SOX (SO2 Scrubber) is attached to the rear of the Model 6060 and plumbed in series to remove any SO2 gas that may be present. If there are other sulfur gases present in the sample gas, they will pass through the SOX scrubber and TRS converter unaffected and not measured. The 6060 Analyzer offers a bright color display, data logging capability and advanced communications via Ethernet, USB and RS-232/485.

The Model 6030 Ozone Primary Standard is NIST traceable and provides an accurate and convenient means of measuring low levels of ozone in ambient air. Using the Beer-Lambert law, ozone is measured in a single photometric cell by detecting the absorption of ultraviolet (UV) radiation from ozone molecules at a wavelength of 254 nm.

The Model 6022 UV H2S Analyzer provides accurate measurement of CS. (Combined Sulfur) or H2S (Hydrogen Sulfide) gas in air or low source. levels from industrial processes. The Model 6022 H2S analyzer uses the. same optical bench as the Model 6020 UV Sulfur Dioxide analyzer. An. efficient H2S converter thermally converts H2S to SO2. SO2 (Sulfur. Dioxide) gas that may be present in the sample gas passes through the. H2S converter unaffected. H2S and SO2 combined in the sample gas is. called CS. If H2S gas is the gas of interest, a SOX (SO2 Scrubber) is. attached to the rear of the Model 6022 and plumbed in series to remove. any SO2 that may be present. If there are other sulfur gases present in. the sample gas, they will pass through the SOX scrubber and H2S. converter unaffected and not measured.

The Model 6042 NT/NH3/NOX Analyzer provides accurate measurement of NT (Total Oxides of Nitrogen), NH3 (Ammonia) and NOX (Oxides of Nitrogen) gas in air or low source levels from industrial processes. The Model 6042 NH3 analyzer uses the same optical bench and electronics as the Model 6040 NO/NO2/NOX Analyzer and will be referred to as the NOX analyzer. The Model 6042 uses the chemiluminescence method for measurement.

Users can easily perform precise gas dilution, ozone, and gas phase titration (GPT) calibrations with the Model 4010 Gas Dilution Calibrator. Enhanced with the latest technology, the Model 4010 was designed to set a new standard of quality and performance for a variety of applications in ambient air monitoring including trace levels, continuous emission monitoring (CEM), fugitive emissions, odor and process monitoring.

The 2010D Intelligent Gas Dilution Calibrator can easily perform gas dilution, multi-source gas blending, ozone and gas phase titration (GPT) for environmental, laboratory, or point source monitoring.
