Smith & Loveless Inc. products

Designed for small to very large plants the SCHLOSS™ Mark VIII-A™ Bar Screens are particularly well suited where larger materials may be present such as hospitals, prisons and similar applications. An optional, fully enclosed Mark VIII-A™ has electrical heating and insulation for colder climates. The screen can also provide weather protection for the screening container which is located behind a door and inside the housing unit. Full enclosures are also available for odor and vector control without the heating and insulation.

Designed for small and large-sized wastewater treatment facilities, distinctive S&L  SCHLOSS™ Mark IX™ coarse bar screens deliver remarkably reliable screening performance with minimal maintenance. These front-cleaned, front-returned reacher screens incline to angles of 75° through 90° and can be pivoted to incorporate in plants with no bypass channel.

Single or dual rake arm selection, precision pin rack assembly design, and customized system options make the S&L SCHLOSS™ Mark CI™ Pin Rack Screen the cost-effective choice for efficient coarse screening for mid-size to large treatment plants and industrial applications with bulky material.

Catenary multiple rake arm screen technology offers proven performance for small to large flow applications with large, bulky material. What separates the S&L SCHLOSS™ Mark CT™ Catenary Bar Screen originates from our detailed engineering in the critical elements: exclusive chain design, superior component materials of construction, and rakes that combat problem flushables and large material.

Designed for smaller in-channel flows, the S&L SCHLOSS™ Mark XV-A™ cost-effectively achieves superior fine screening. Its robust design combines an inclined, stationary screen basket with a conveying screw featuring an outer spiral brush for cleaning. The screen basket incorporates perforated sheet (recommended) or wedge wire screening, while the higher efficiency shafted screw design provides increased durability and service life when compared to imported, shaftless designs. Screenings are washed and dewatered uniquely in a trouble-free plug-type compaction zone.

Reduce solids, scum and waste disposal costs with the S&L SCHLOSS™ Mark XV-C™ Fine Screw Screen system. Designed for larger in-channel flows, the Mark XV-C™ cost-effectively achieves fine screening through a robust design that combines a cylindrical screen basket with internal rotating rake arm, brush cleaning, and shafted screw conveyor. The unique S&L SCHLOSS™ screen basket design eliminates the potential for bar breakage from problem solids like broken glass and gravel. Removed solids are washed and dewatered, and they can be compacted and optionally bagged.

Smith & Loveless takes its prominence in water and wastewater products even further with the OBEX™ Spiral Fine Screen system, complete with PLC controls and a color HMI screen.  The OBEX™ Spiral Fine Screen system is a high-performance system which protects equipment and enhances plant operations by removing trash items and debris from treatment processes.
