Significant reduction of carbon, nitrogen and phosphorus pollution
High and simultaneous removal of bacteria depending on the treated water, completed by downstream disinfection.

Veolia also offers "Biosep™ Pack", new standard membrane filtration units:

Flexible and modular solutions
Guaranteed performances identical to those of the conventional Biosep™ process

Biosep™ is sold under the Neosep™ trademark in Japan, the United States, Australia and New Zealand.

Biosep™ for Industries

The Biosep™ technology meets the specific requirements of industrial clients, when they are confronted with the following problems:

Concentrated effluents
High discharge standards and treatment efficiency
Upgrade/refurbish existing facilities
Water reuse
Limited space available

Biosep™ achieves high-performance treatment of industrial effluents for the following markets:

Food and beverage
Pharmaceuticals
Cosmetics
Chemicals
Petrochemicals
Biofuels
Landfill leachate
Pulp and paper
Automotive
Textiles…

Biosep™ for Municipalities

Biosep™ is a membranes bioreactor developed by Veolia. It is an activated sludge process in which membranes provide the clarification.

Biosep™ is suitable for municipal clients who:

Must adhere to high discharge standards (environmentally sensitive areas)
Want to achieve high wastewater treatment efficiency
Have a limited area to operate in
Want to reuse water for irrigation, for use in sprinkler systems or for recharging aquifers

Biosep™ is ideal for meeting the requirements of municipal clients who experience sharp seasonal load variations (touristic areas). Biosep™ also enables the purified water to be released directly back into environmentally sensitive areas, thereby avoiding the construction of long outfalls.

Advantages of the Biosep™ Process for Municipal Clients:

Membranes provide clarification; the load applied can be significantly higher than in a classic activated sludge. For the same load, the reactor is smaller so, the plant is more compact
Thanks to its compactness, the structure can be easily confined, and odor and noise nuisances are controlled
On mixed wastewater, Biosep™ is free of risks related to fibrous sludge bulking
By undergoing an additional UV treatment, the water treated by Biosep™ can be reused in irrigation, sprinkler systems or for recharging aquifers
Biosep™ is ideal when refurbishing existing sites, thanks to its compact design and the fact that it can be easily installed in existing tanks

Some municipal references:

Saint Laurent du Var, France (2013), 110,000 PE
Disneyland Paris, France (2013), 20,000 PE
Saint Nazaire, France (2012), 75,000 PE
Monnaie, France (2012), 5,600 PE
Achères DERU - Seine Aval, France (2011), 110,000 PE
Port Leucate, France (2011), 45,000 PE
Ashbourne, Ireland (2006), 5,000 PE
Avranches, France (2006), 40,000 PE
Rousset, France (2006), 12,000 PE
Saint-Jouan des Guérêts, France (2006), 7,500 PE

Features & Benefits

Biosep™ provides water of exceptional quality:

High reduction of carbon and nitrogen pollution
High suspended matter removal
High bacteria removal rate

Biosep™ has many advantages compared with conventional biological treatment of effluents by activated sludge:

Compact system
No final clarification (no risk of sludge loss, performance is independent of the sludge index)
With a similar load, the biological reactor is smaller
High COD removal, including slowly biodegradable COD thanks to a high "sludge age" and membrane separation
Reduced reagent consumption in phosphorus elimination
Thickener may also be removed because of the high concentration reached in the biological reactor
