AMETEK Process Instruments products

The IPS-4 is a cost-effective, low maintenance photometric spectrometer with the ability to measure up to eight analytes in a gas or liquid phase sample. Available in UV-VIS, NDIR and IR/UV platforms, it provides a fully integrated sample conditioning system for easy maintenance. The IPS-4 has an IP65enclosure and is durable enough for use in harsh environments.

The 888 utilizes ultraviolet (UV) spectroscopy to accurately monitor hydrogen sulfide (H₂S) and sulfur dioxide (SO₂) concentrations in sulfur recovery tail gas. The analyzer delivers next-level reliability, with automatic flow control, flange temperature alarm and an extended ambient temperature range providing solutions to the most common external failure modes.

Using high-resolution ultraviolet (UV) technology in a dual-beam, multiple-wavelength configuration, the 900 is specifically designed to meet the demanding analytical requirements of modern sulfur recovery processes. Capable of measuring up to four species simultaneously, this air demand analyzer is uniquely capable of monitoring off-ratio applications, providing accurate chemical concentration data over wide dynamic ranges.

Capable of measuring up to five different gases simultaneously, the 910 is a complete analysis system, with a sample extraction and transport designed for maintaining sample integrity. Delivering multi-component analytical performance that typically requires two or more separate analyzers, it provides a cost-effective alternative for the monitoring of multiple gases. An optional zirconium oxide sensor can be added to measure oxygen.

The  914 is a built-to-order Continuous Emission Monitor (CEM) that includes all the components needed for a compliance monitoring and reporting project. The system uses dry extractive sampling techniques designed to meet government regulations for all types of compliance monitoring.

The 919 is a fully extractive hot-wet gas analyzer, providing a complete monitoring system with sample extraction and transport, designed to maintain sample integrity. Developed to meet the requirements of the most challenging process and emissions monitoring applications in a cost-effective way, it delivers high reliability and reduced maintenance, with no moving parts.

The 920 is a multi-gas analyzer specifically configured to monitor the stack emissions of multiple pollutants on a concentration basis. Combining hot-wet analysis with reliable ultraviolet-based measurements, the 920 delivers multi-range sulfur dioxide measurements, alongside simultaneous, independent measurements for nitric oxide and nitric dioxide.

Using proven ultraviolet (UV) technology, the 930 identifies potential safety risks in sulfur storage locations through simultaneous hydrogen sulfide (H₂S) and sulfur dioxide (SO₂) measurements. Capable of stable, sensitive measurements ranging from parts-per-million (ppm) to percentage levels, the analyzer offers output alarms for the lower explosive limit of H₂S and smoldering fire level of SO₂.

Measuring hydrogen sulfide (H₂S), the 931 is a rugged, single-ultraviolet (UV) component photometric analyzer with a low-maintenance, no-moving-parts design, housed in an explosion-proof package. It can also be configured for primary measurements of sulfur dioxide (SO₂), carbonyl sulfide (COS), carbon disulfide (CS₂) or ammonia (NH₃), and provided with a thermal conductivity detector (TCD) for the measurement of hydrogen (H₂).

Housed in an explosion-proof package, the 932 is a multi-component ultraviolet (UV) photometric gas analyzer which measures up to five gas species at the same time. Hydrogen sulfide (H₂S) and sulfur dioxide (SO₂) are the primary measured components. The analyzer can also be configured to measure carbonyl sulfide (COS) and/or carbon disulfide (CS₂).
