HITEMA INTERNATIONAL S.R.L. products

ENR Series are aircooled liquid chillers, designed for industrial use and for outdoor installation. These chillers are designed for applications that require reliability, continuity of operation, high performance and reduced management costs. All models are equipped with coaxial or shell and tube evaporator (except for models 001÷002) that ensures reliable operation in particular with liquids containing impurities. All models are equipped with water pump suitable to work with water-glycol mixture and storage tank to assure precise control of temperature even in the presence of highly variable thermal loads from the process.

ENRF SERIES are aircooled liquid chillers, designed for industrial use and for outdoor installation. These chillers are designed for applications that require reliability, continuity of operation, high performance and reduced management costs. All models are equipped with coaxial or shell and tube evaporator that ensures reliable operation in particular with liquids containing impurities. All models are equipped with water pump suitable to work with water-glycol mixture and storage tank to assure precise control of temperature even in the presence of highly variable thermal loads from the process. Moreover this chillers have an integrated free-cooling pack with copper tubes and aluminum finned core, which allows considerable energy savings, particulary where there are cold climates

CSE SERIES are aircooled liquid chillers, designed for industrial use and for indoor installation. These chillers are designed for applications that require reliability, continuity of operation, high performance and reduced management costs. All models are equipped with coaxial or shell and tube evaporator that ensures reliable operation in particular with liquids containing impurities. All models are equipped with water pump suitable to work with water-glycol mixture and storage tank to assure precise control of temperature even in the presence of highly variable thermal loads from the process. Centrifugal fans, with their 250 Pa available pressure, assure the possibility to canalize the air exiting from them.

ICE-RINK SERIES  consists of Standard and Customized Air-Cooled Chillers designed for applications that require reliability, continuity of operation, high performance, reduced management costs and Ice-Rink process.

CFT SERIES are aircooled liquid chillers, designed for air conditioning use and for outdoor installation. These chillers are designed for applications that require reliability, high performance and reduced management costs. All the models are equipped with brazed plate evaporator. On request all the models can be equipped with water pump suitable to work with water-glycol mixture and storage tank to assure precise control of temperature even in the presence of highly variable thermal loads.

Standard Configuration: Compressors:Scroll. Condenser:Air-Cooled, with copper tubes and aluminium finned core. Evaporator:Brazed plate (SBS.095÷SBS.160) or Shell & Tube (SBS.190÷SBS.1230). Expansion Valve: Thermostatic (SBS.095÷SBS.430) or Electronic (SBS.470÷SBS.1230). Fans: AC axial. Protection Rating: IP54. Refrigerant: R410A, R454B; R32.

Standard Configuration: Compressors: Scroll. Condenser: Air-Cooled with integrated Free-Cooling coil, with copper tubes and aluminium finned core. Evaporator: Brazed plate (SBSF.095÷SBSF.120) or Shell & Tube (SBSF.145÷SBSF.1030). Expansion Valve: Thermostatic (SBSF.095÷SBSF.430) or Electronic (SBSF.470÷SBSF.1030). Fans: AC axial. Protection Rating: IP54. Refrigerant: R410A, R454B; R32.

Standard Configuration: Compressors: Scroll. Condenser: Air-Cooled, aluminum microchannel condenser coils. Evaporator: Brazed plate (SBS.095÷SBS.160). Expansion Valve: Thermostatic (SBS.095÷SBS.160) Electronic available. Fans: AC axial or EC fans available. Protection Rating: IP54. Refrigerant: R410A, R454B; R32. Cooling Capacity Range 95kW ÷ 180kW.

Standard Configuration: Compressors: VSD Screw. Condenser: Air-Cooled, with copper tubes and aluminum finned core. Evaporator: Shell & Tube. Expansion Valve: Electronic. Fans: AC axial. Protection Rating: IP54. Refrigerant: R134a. R134a; R513A and R1234ze. Cooling Capacity Renge 300kW ÷ 1390kW.

Standard Configuration:. Compressors:VSD Screw. Condenser:Air-Cooled with integrated Free-Cooling coil, with copper tubes and aluminium finned core. Evaporator:Shell & Tube. Expansion Valve: Electronic. Fans: AC axial. Protection Rating: IP54. Refrigerant: R134a; R513A and R1234ze. Cooling Capacity Renge: 300kW ÷ 912kW.
